Diesel & Heavy Duty
Duramax, Powerstroke, Cummins — plus semi trucks.
21 skill areas
60 key concepts
$0 to learn
Diesel & Heavy Duty covers diesel-powered light-duty trucks (Duramax, Powerstroke, Cummins) and Class 7-8 heavy-duty operations. Premium-value certification. Everything below is free — no login, no paywall. Work through the skill areas, drill them in Study Mode, and when you're ready, prove it with the certification exam.
0%
ready
NOT STARTED
Your readiness to certify
Drill all 60 concepts in Study Mode. Mark each one “Got it” once you know it cold. When every concept is cleared, you're ready for the DSL exam.
0 got it
0 to review
60 untouched
What you'll be able to do
- Diesel fuel systems: high-pressure common rail, HEUI, mechanical injection
- Turbocharger diagnosis and service (VGT, twin-turbo)
- DPF (diesel particulate filter) service and regeneration
- EGR system diagnosis and service
- DEF (diesel exhaust fluid) system diagnosis
- Fuel injector testing (electronic and mechanical)
- Boost leak testing methodology
- Class 7-8 introductions: air brake, PTO, heavy-duty electrical
Skill areas
Jump to any area — each one distills the concepts you need to master it.
Fundamentals
2 concepts- Diesels compress air to a temperature high enough to ignite fuel injected at the top of the compression stroke — no spark plugs needed.
- Diesel compression ratios range from about 16:1 to 22:1, needed to raise intake air temperature to auto-ignition temperature.
Fuel
3 concepts- ULSD is 15 ppm or lower. Required for all on-road diesel vehicles in the US since 2010 to protect emissions equipment (DPF, SCR).
- Red-dyed diesel is untaxed and only for off-road use. Using it in on-road vehicles is federal and state tax evasion. Fines are severe.
- Cetane number (typically 40-55 for on-road diesel) measures how readily the fuel ignites. Higher = smoother combustion, easier cold starts.
Injection Systems
4 concepts- Modern common-rail diesels use pressures from 20,000 to 40,000+ psi for fine atomization and precise multi-shot injection events.
- High-pressure fluid injection injuries look minor but require immediate emergency care. Never search for leaks with your hand — use cardboard.
- HEUI uses a high-pressure oil pump (HPOP) at up to 3000 psi to trigger injectors mechanically. Common on older Powerstroke engines.
- Electronic control allows pilot, main, and post injections in a single cycle — reducing NOx, particulates, and combustion noise.
Turbocharger
2 concepts- VGT vanes close at low RPM (small A/R for quick spool) and open at high RPM (large A/R). Vane sticking from soot is a common failure.
- Soot fouls VGT mechanisms. Stuck-closed vanes overboost. Stuck-open underboost. Regens or cleaning are the fix; severe cases require replacement.
Emissions
8 concepts- DPF traps soot (particulate matter). When full, active or passive regeneration burns it off — raising exhaust temp to convert soot to ash.
- Active regen fires when DPF loading exceeds a threshold. Fuel injected late (or in a 9th injector into the exhaust) raises DPF temp to burn soot to ash.
- Regen burns soot to ash, but ash accumulates and must be manually cleaned (via professional service) or the DPF replaced. Typical life: 100k-200k mi.
- SCR mixes DEF (32.5% urea, 67.5% deionized water) with hot exhaust over a catalyst, converting NOx to harmless N2 and H2O.
- DEF freezes below 12°F. Vehicles have heated tanks and lines. If DEF freezes solid, the SCR won't inject and the vehicle may derate power.
- EGR routes cooled exhaust back into intake, lowering peak combustion temp and reducing NOx formation. Trade-off: increased soot production.
- EGR cooler failures are common on many diesels. Coolant into intake = white steam smoke, coolant loss, and potentially hydro-lock (bent rods, cracked heads).
- Deleting emissions equipment on on-road diesels violates federal law. EPA has aggressively pursued shops and owners with major fines.
Powerstroke
2 concepts- 6.0L Powerstroke has known failure of EGR coolers and stacked oil cooler restrictions. Common upgrades include improved oil cooler, EGR cooler, head studs, and injectors.
- 6.7L Powerstroke has had radiator, EGR cooler, and (on 2011-2014) turbo bearing failures. Fuel system contamination is also common if the CP4 pump fails.
Duramax
2 concepts- LB7 injectors were placed under the valve covers — replacement requires significant labor. Common warranty extension and known issue.
- CP4 pumps can fail catastrophically, sending metal shards through the injectors. Repair cost: $10-15k+ including tank, lines, pump, injectors, rails.
Cummins
2 concepts- Original in-tank lift pumps couldn't reliably supply fuel to the frame-mounted VP44. Upgrade to FASS or AirDog aftermarket lift pump is common and extends injection pump life.
- Aborted regens leave soot in the DPF. Complete cycles when possible. Frequent short trips or idling worsen DPF loading.
Cold Start
2 concepts- Cold intake air can prevent auto-ignition. Grid heaters warm intake charge; glow plugs heat the combustion chamber; block heaters keep coolant warm.
- Ether ignites at lower temp than the glow plug/grid heater surface, causing pre-ignition and detonation. Never use ether on engines with intake heating systems.
Injector
3 concepts- Stuck injectors dump fuel into cylinders when they shouldn't. Combustion pushes fuel past rings into the crankcase, diluting oil and creating a fire risk.
- Balance/contribution tests compare each injector's power output. Weak or dead injectors show as outliers, guiding diagnosis without disassembly.
- Modern piezo and solenoid injectors have serial numbers with calibration data. Replacements must be coded to the ECM for correct fuel metering.
Water in Fuel
2 concepts- Diesel systems need lubricity — water rusts internals and destroys HPFP pumps and injectors. Drain the fuel-water separator immediately when the light comes on.
- Regular draining prevents water accumulation. Some vehicles have manual drain valves; others have automated systems that alert.
Filters
2 concepts- Diesel filters have very tight microns (2-4 micron on modern common-rail). Clogged filters starve HPFP and injectors, causing severe damage.
- Restricted filters reduce air, cause smoke, and increase fuel dilution. Replace at the indicator threshold, not on a fixed interval.
Oil
2 concepts- CK-4 is for older and current engines. FA-4 is for newer, fuel-economy-optimized engines. Wrong oil can plug DPFs (from wrong ash characteristics) or wear engines.
- Late-cycle regen fuel can wash past rings into the crankcase. Extended short-trip use amplifies dilution. Monitor oil level — rising oil indicates fuel dilution.
Air System
4 concepts- Boost leaks let air escape before the engine, reducing charge and creating rich conditions. Pressure test intake at operating boost with smoke or pressure to locate.
- Systematic pressure testing isolates the leak location. Intercooler-only tests confirm whether the core itself is cracked.
- Closed EGR = no recirculation = higher peak combustion temp = more NOx. PCM sees insufficient flow and codes it.
- EGR soot builds over miles. Cleaning restores function; severely fouled valves are replaced. Modern engines often diagnose and set specific codes.
Diagnostics
6 concepts- White steam-like smoke smells sweet from ethylene glycol. Pressure test cooling system and pull EGR cooler for inspection. On some engines, cracked heads or gaskets are common.
- Black smoke is unburned soot. Excess fuel or insufficient air causes it. Diagnostic path: air first (filter, boost, VGT), then fuel.
- Blue smoke = oil in combustion. Sources: piston rings, valve seals, or turbo seals letting oil into intake/exhaust.
- Diesel runaway: engine runs on fuel it can't control. Shut off by blocking the intake with a rag or covering the air intake. Damage is often severe if not stopped fast.
- Diesel no-start diagnostic: verify fuel pressure at rail, verify injector command, check compression, check for crank/cam sync loss.
- HPFP failure progresses from performance loss to catastrophic failure. Catch it early via rail pressure logs; late failure contaminates the entire system.
Heavy Duty
5 concepts- CVSA inspection criteria have specific pushrod stroke, drum lining, and adjustment requirements. Failing brakes puts a truck out of service on the spot.
- Air brakes use compressed air to actuate S-cam or disc foundation brakes. Spring brakes provide fail-safe parking — spring applied, air released.
- Compressors create moisture that collects in the wet tank. Draining daily (or via automatic drain valves) prevents freeze-related brake failure.
- CDL classes are based on weight rating and vehicle type. Mechanics don't always need one, but road-testing may require it depending on GVWR.
- Jake brake dumps compression through the exhaust, using the engine as an air compressor. Very effective braking; loud (banned in some jurisdictions).
Injection
2 concepts- High-pressure rail sensors are inside the fuel path. A leak sprays diesel at high pressure and causes rail pressure faults. Replace at first sign of leak.
- Momentary run after start means fuel is in the rail but not being replaced. Check lift pump operation, tank pickup, and injector return check valves.
Cold Weather
2 concepts- Diesel wax content precipitates at cold temps. Winter blends and anti-gel additives lower CFPP for cold-climate operation.
- Fuel stations blend #1 diesel (kerosene) with #2 to lower gel point. Blending ratios depend on ambient temperature.
Regulation
2 concepts- CARB Truck & Bus Rule and related programs mandate emission compliance for CA-registered and CA-operated diesel vehicles by age. Non-compliance blocks registration.
- California requires smog inspection for most diesels. OBD readiness, visual emission equipment inspection, and opacity may all be checked.
Safety
2 concepts- Common rails hold high pressure for time after shutdown. Follow manufacturer depressurization procedures before disconnecting lines to avoid injection injuries.
- Diesel injection components have micron-level tolerances. Clean-room conditions and lint-free wipes are essential. Contamination causes premature failure.
Documentation
1 concept- Consumer protection rules require detailed invoicing. Fleet/DOT records must be kept longer for driver/vehicle qualification files and roadside inspection defense.
READY TO PROVE IT?
Studied the material? Get DSL certified.
The Diesel & Heavy Duty exam turns what you just learned into a verifiable credential drivers and shops can look up. 75 questions · 90 minutes · 78% to pass · $19.99.
Studying here is free forever. There's no obligation to take the exam.
